Axon Synapse modular broadcast signal processing frame, fitted with a versatile combination of HD/SD video, audio, sync, fibre, and control modules.

Includes dual redundant power supplies and Ethernet control.
Tested, cleaned, and supplied with a 3-month warranty.

Configuration:

• 1 × SFR18 4RU frame (18 slots, dual PSU, Ethernet control)

• Slot 1 – SIM11 — System controller / Ethernet / GUI
• Slot 2 – SVD20 — HD-SDI frame sync + Up/Down/Cross conversion
• Slot 3 – SVD10 — HD-SDI frame sync
• Slot 4 – SVD10 — HD-SDI frame sync
• Slot 5 – VWI20 — Video ↔ Fibre I/O
• Slot 6 – VW120 — HD-SDI video distribution / I/O
• Slot 7 – VW120 — HD-SDI video distribution / I/O
• Slot 8 – VW120 — HD-SDI video distribution / I/O
• Slot 9 – VW120 — HD-SDI video distribution / I/O
• Slot 10 – VW120 — HD-SDI video distribution / I/O
• Slot 11 – HS121 — HD signal processing
• Slot 12 – INS20 — Input selector
• Slot 13 – INS20 — Input selector
• Slot 14 – SEB11 — Sync / reference distribution
• Slot 15 – DAD08 — Digital audio de-embedder
• Slot 16 – ADC20 — Audio conversion / processing
• Slot 17 – 21X08 — System control / signal interface
• Slot 18 – 2HU101 — Utility / monitoring interface

Condition:

• Excellent used condition, professionally de-installed (a couple of light scratches to paintwork on front casing)
• Fully tested prior to listing
• All cards and matching rear modules included
• Internal fans and dual PSUs verified operational
• 3-month warranty included

Applications:

Ideal for broadcast facilities, OB trucks, studios, post-production, and signal-management environments.
This system provides flexible HD/SD video distribution, frame synchronisation, audio de-embedding, fibre I/O, sync distribution, and robust system control — a powerful multi-purpose configuration ready for deployment.

Multiple systems available across my other listings – open to sensible offers on multi‑buy packages
