Extra Information Features
Bandwidth 4:2:2 HDSDI output
Built-in Genlock
Support of 1080i / 720p / 480i
XDCAM EX codec
Focus Assist function
Industry standard bayonet lens mount
4.3" Flip-out monitor
Compact Shoulder form factor
Dual SDHC memory recording
Data rates: 19Mbps, 25Mbps, 35Mbps
Ready -to-edit files (.mov, .mp4, .avi)
Pool feed input
Time code IN/OUT
1.22 megapixel viewfinder
Optional ASI module
Specifications
General
Power: DC 12V (11-17V)
Power consumption: Approx. 27W (Recording mode with standard lens and LCD monitor in use)
Weight: Approx. 3.9kg
Operating temperature: 0oC to 40oC (32oF to 104oF)
Storage temperature: -20oC to 60oC (-4oF to 140oF)
Operating humidity: 30% to 80% RH
Storage humidity: Under 85%
Camera
Image sensor: 1/3" Progressive scan 3CCD
Lens: Canon F1.6, 14x, f=4.4-61.6mm (35mm conversion:32 to 448mm)
Lens mount: 1/3" bayonet system
Filter diameter: 82mm
Shutter speed: 1/6 to 1/10000, EEI
Gain: 0dB, 3dB, 6dB, 9dB, 12dB, 15dB, 18dB, ALC
ND filter: OFF, +1/4 ND, +1/16 ND
Minimum illumination: 1.25lx (typical) (1920x1080 mode, F1.4, +18dB, with 8-frame accumulation)
Synchronizing system: Internal sync: buit-in SSG / External sync: BB, VBS signal or HD tri-sync signal
LCD display: 4.3" LCD, 800 x 480 (WVGA, 410,000 pixels)
Viewfinder: 0.45" LCOS, 1,226,000 pixels (852 x 480 x 3)
Video/Audio
Recording media: SDHC memory card (Class 6 or Class 10), 2 slots
Video recording
Video codec: MPEG-2 Long GOP
File Format: Quick time format for Final Cut Pro/mp4 file format
HD Recording mode
HQ mode: VBR, 35Mbps (1920 x 1080i 50/60, p24/25/30) MPEG-2 MP@HL
SP mode: CBR, 25Mbps (1440 x 1080i 50/60) / 19Mbps (1280 x 720p 24/25/30)MPEG-2 MP@H-14; 19Mbps (1280 x 720p 50/60) MPEG-2 MP@HL
SD Recording mode: DV compression 4:1:1(NTSC: GY-HM790U only)/4:2:0(PAL: GY-HM790E), 8-bit, 25Mbps
Video Frame Rate
NTSC setting HD HQ mode:
1920x1080/59.94i, 29.97p, 23.98p, 1440x1080/59.94i (MOV only), 1280x720/59.94p, 29.97p, 23.98p
HD SP mode: 1440x1080/59.94i, 1280x720/59.94p 29.97p, 23.98p
NTSC SD mode: 480/59.94i (GY-HM790U only)
PAL setting HD HQ mode:
1920x1080/50i, 25p, 1440x1080/50i (MOV only), 1280x720/50p, 25p
HD SP mode: 1440x1080/50i, 1280x720/50p, 25p
PAL SD mode: 576/50i (GY-HM790E only)
HD HQ 720p mode - NTSC setting: 10/12/15/20/24/30/40/48/60fps / PAL setting: 10/12.5/20/25/40/50 fps
Audio recording
HD: Linear PCM 2ch, 48 kHz / 16 bit, SD: Linear PCM 2ch, 48 kHz / 16 bit or 4ch, 32 kHz / 12 bit
